Dugan Models E-1 and E-1A User Guide
51
Appendix B: Connector Pinouts
Table 2-1 Analog I/O jacks
Table 2-2 10 BASE T (Ethernet, TCP/IP)
Part Signal
Tip Input
Ring Output
Sleeve Ground
Pin Signal
1 T2
2 T1
3 R2
4 n/c
5 n/c
6 R1
7 n/c
8 n/c
