Doremi MCSHD - Manual (Page 51)

segment number. If the segment selected in this option is 0, the loop will be the
entire length of the file (24 hours).
LoopMode Select between OFF and ON. When ON the V1 will loop back to beginning of
the file when it reaches the end of the file or segment as specified in
“LimToSeg” above. When set to OFF the V1 will stop at the end of the file.
Emulate Select between V1 (default), BVW-75, DVW-500, Odetics, Odetics LMTD,
VDCP (Louth) and RS-232C.
StepRec This option is for Step Recording. When enabled, every time the V1 goes into
record, it will only record one frame. This option is useful for animation. When
Step Recording is disabled, the V1 is in normal mode of operation.
Select ALL to record the video and audio. If you want to record video only
without altering the previously recorded audio, select Video.
Rec at The function tells the V1 to record at the current position (Cur P.) or at the end
of the last recorded video in the file (End F.). If you are working in any of the A-
Time modes and want to avoid recording over existing material, set this option
to End F.
Note : Rec at: End F. is not valid if the Time Mode is set to Time Code. In those
this mode, the unit will synchronize to the incoming time code to determine the
recording position.
10.2 Auto Play
The Auto Play settings allow the V1 to automatically start playing a segment when the V1 is
powered on and the drive is mounted.
Auto Play Enter a predefined segment number. The V1 will now play that segment every
time it mounts that drive. This function can also be used to automatically locate
to a start point every time the disk is mounted. All you need to do is set the IN
and OUT time at the same location for the auto-play segment.
NoVidDly 000s V1 Screen Saver. This parameter sets the delay until the video output goes
black (screen saver) in 10 second increments. "000" will disable this feature.
Example: "010" will cause the unit to output black video when the unit is idle for
10 seconds.
10.3 New Rec Set
The New Record Settings contain all the main options used to define a V1 File.
If you are using multiple files on the V1 you must create a new file after changing a setting in this
section. For instructions on how to create a file, see Section 6.1.2.
If you are using a single file (the default file created by the V1) you will need to reinitialize after
changing a setting in this section - See Section 10.7.
V_1.OM.000160.DRM Page 51 of 85 Version 5.2
