15
4. OSD Menu
An overall view of the On-Screen Display (OSD) structure is
shown below. You can use it as a reference for further adjusting
your display.
4.1. Navigating the OSD Menu
4.1.1. Navigating the OSD menu using the
remote control
EXIT
MENU
SET
1. Press [ MENU] button on the remote control to display the
OSD menu.
2. Press [ ] or [ ] button to choose the item you want to
adjust.
3. Press [ SET] button to enter the submenu.
4. In the submenu, press [ ] or [ ] button to toggle among
items, press [ ] or [ ] button to adjust settings. If there is a
submenu, press [
SET] button to enter the submenu.
5. Press [ EXIT] button to return to the previous menu, or press
[ MENU] button to exit the OSD menu.
4.1.2. Navigating the OSD menu using the
display’s control buttons
1. Press [ MENU] button to display the OSD menu.
2. Press [ ] or [ ] button to choose the item you want to
adjust.
3. Press [ SOURCE] button to enter the submenu.
4. In the submenu, press [ ] or [ ] button to toggle among
items, press [ ] or [ ] button to adjust settings. If there is a
submenu, press [ SOURCE] button to enter the submenu.
5. Press [ MENU] button to return to the previous menu, or
press [ MENU] button several times to exit the OSD menu.
4.2. OSD Menu Overview
4.2.1. PICTURE menu
PIP
1
2
3
SET EXIT MENU :SEL :NEXT
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
TINT
COLOR
COLOR TEMPERATURE
USER COLOR
GAMMA SELECTION NATIVE
NATIVE
NOISE REDUCTION
FILM MODE
PICTURE RESET
:RETURN :EXIT MENU
50
50
70
50
BRIGHTNESS
Adjust the overall image brightness by changing the intensity of
the LCD panel’s backlight.
CONTRAST
Adjust to sharpen the picture quality. The black portions of
the picture become richer in darkness and the white become
brighter.
SHARPNESS
Adjust to improve the image detail.
BLACK LEVEL
Adjust to change the image brightness.
TINT
Use the [ ] or [ ] button to adjust. Press the [ ] button and
the flesh tone color turns slightly green. Press the [ ] button
and the flesh tone color turns slightly purple.
NOTE: This item is functional for
HDMI(Video mode), S-Video,
Video, and YPbPr inputs only.
COLOR
Adjust to increase or decrease the intensity of colors in the
image.
NOTE: This item is functional for
HDMI(Video mode), S-Video,
Video, and YPbPr inputs only.
COLOR TEMPERATURE
Select a color temperature for the image. A lower color
temperature will have a reddish tint, whilst a higher color
temperature gives off a more bluish tint.
The options are: {
3000K} / {4000K} / {5000K} / {6500K} / {7500K}
/ { 9300K} / {10000K} / {NATIVE} / {USER}.
USER COLOR
With this function you can adjust the color tones of the image
precisely by changing the R (Red), G (Green) and B (Blue)
settings independently.
NOTE: This item is functional only when {
COLOR
TEMPERATURE} is set to {USER}.
