NE1000 CATV Optical Transmitter Operation and Maintenance Guide
FRONT PANEL
A diagram of the NE1000 is shown in Figure 1. The NE1000 features are
described below.
1.
AC POWER LED - Lights up when the transmitter is receiving AC power.
2.
LASER POWER LED - Lights up when the laser is switched on.
3.
LASER ON/OFF KEY SWITCH – Turns on/off the power to the laser.
4.
POWER LED - Illuminates when the output power of the LASER is outside the
range of maximum or minimum acceptable power.
5.
TEMP LED - Lights up when the laser temperature is abnormal.
6.
BIAS LED – Illuminates when the biasing current of the LASER is abnormal.
7.
HIGH LED - Lights up when the power of the input RF signal is above normal.
8.
NORMAL LED - Illuminates when the power of the input RF signal is normal.
9.
LOW LED - Lights up when the power of the input RF signal is below normal.
10.
MGC (Manual Gain Control) Adjustment – For manually setting the
transmitter gain when the transmitter is in MGC mode.
11.
AGC (Automatic Gain Control) Adjustment – For setting the output power of
the transmitter when the transmitter is in AGC mode.
12.
RF MONITOR -20dB – 75
Ω F-type connector test port for measuring input
signal level at 20 dB
±1.5 dB lower than the actual signal.
REAR PANEL
1.
ON/OFF Switch – Used to turn transmitter on or off.
2.
POWER JACK – For supplying power to the transmitter.
3.
FUSE – A 250V 3.15A fuse to protect the transmitter against short circuits and
