Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
quadravision mode
Pip1 Layer for
output 2 in matrix
mode
6 = Logo 1
7 = Logo 2
8 = Audio Output 1
9 = Audio Output 2
PE_POS_H pH pH
Layer left H position on output
screen
Rd/Wr 0 65535 32768
Unit = pixels ( 32768 =
screen left border )
0 = Current preset
1 = Next preset
2 = Previous preset
3 = Memory Preset 1
4 = Memory Preset 2
5 = Memory Preset 3
6 = Memory Preset 4
7 = Memory Preset 5
8 = Memory Preset 6
9 = Memory Preset 7
10 = Memory Preset 8
0 = Background
Frame for output 1
1 = Background
Frame for output 2
in matrix mode
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
4 = Pip 2 Layer for
output1
5 = Pip 3 Layer for
output1 in
quadravision mode
Pip1 Layer for
output 2 in matrix
mode
6 = Logo 1
7 = Logo 2
8 = Audio Output 1
9 = Audio Output 2
PE_POS_V pV pV
Layer top V position on output
screen
Rd/Wr 0 65535 32768
Unit = pixels ( 32768 =
screen top border )
0 = Current preset
1 = Next preset
2 = Previous preset
3 = Memory Preset 1
4 = Memory Preset 2
5 = Memory Preset 3
6 = Memory Preset 4
7 = Memory Preset 5
8 = Memory Preset 6
9 = Memory Preset 7
10 = Memory Preset 8
0 = Background
Frame for output 1
1 = Background
Frame for output 2
in matrix mode
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
4 = Pip 2 Layer for
output1
5 = Pip 3 Layer for
