6

Group

Name

Cmd RespDescription

Read /
Write

Min
Value

Max
value

Default
value

Values

Index #1

Index #2

MATRIX_MIRROR

Cm Cm

Enable/Disable the mirror mode in
matrix mode

Rd/Wr 0

3

0

0 = No copy
1 = Full copy
2 = Source copy and position H
Flip
3 = Source copy, data and
position H Flip

0 = Background
Frame for output 1
1 = Background
Frame for output 2
in matrix mode
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
4 = Pip 2 Layer for
output1
5 = Pip 3 Layer for
output1 in
quadravision mode
Pip1 Layer for
output 2 in matrix
mode
6 = Logo 1
7 = Logo 2
8 = Audio Output 1
9 = Audio Output 2

AXION

yA yA

Device is driven by Orchestra

Rd/Wr 0

1

0

0 = Device is not driven by
ORC-50
1 = Device is driven by Orc-50

AUTO_LOCK

YL YL

Forbide the use of a signal-less
input

Rd/Wr 0

1

1

0 = Signal less input can be
selected
1 = Signal less input can not be
selected

AUTO_TAKE

YT YT

Automatic Take after an input
change

Rd/Wr 0

1

0

0 = AUTO-TAKE Disable
1 = AUTO-TAKE Enable

AUTO_STEPBACK

Ys Ys

Automatic preset toggle after a
TAKE

Rd/Wr 0

1

0

0 = AUTO- PRESET-TOGGLE
Disable
1 = AUTO- PRESET-TOGGLE
Enable

FREEZE_MODE

Ym Ym Input freeze mode

Rd/Wr 0

1

0

0 = Freeze by input
1 = Freeze all inputs

PROG_KEY_ET

YM YM

ELEMENT TRANSITION of the
effect programmable keys

Rd/Wr 0

4

2

0 = Cut
1 = CleanCut
2 = Fade
3 = Slide (associée à 1
trajectoire)
4 = Wipe (associée à 1
trajectoire)

0 = Fade
programmable key
1 = User 1
programmable key
2 = User 2
programmable key
