Controls, LEDs, and Connectors
MVME2502 Installation and Use (6806800R96E)
57
3.2
Front Panel
The following components are found on the MVME2502 ENP1 and ENP2 front panel.
Figure 3-3
Front Panel LEDs, Connectors and Switches
PMC/XMC 1
USER 1
Reset Switch
SPEED
ACT
SPEED
ACT
Serial Port
USB
ETH 1
ETH 2
PMC/XMC 2
FAIL
