Page 5
09/06 Rev. 3.06-01
OPERATING MANUAL
Device Description
ALX 92x
5
A Optional: Mini-DIN connector
To connect an external operation panel
B Optional: Applicator Interface (AI)
For controlling nearly arbitrary applicator types
C Connection Rotary Encoder
y For automatic speed adaption
y Is not yet supported
D Power switch
Turns the device on/off. An additional switch is located on the control panel
E Power supply
Connection to the power supply using the power cable provided
F Ethernet interface
To connect to an „Ethernet 10/100 Base T“ network
G Status-LED/Ethernet
H RS232 interface
For serial transfer of print data
I
Centronics interface
For parallel transfer of print data (cable is inclusive)
J 2x USB interface type B (device)
To connect devices (e.g. keyboard, scanner)
K USB interface type A (host)
For transfer of print data
L Card slot
For CompactFlash cards; used for storing fonts, logos, graphics, etc.
M Optional: Cable duct for OD control
To connect a photoelectric barrier, which checks the outer diameter of the la-
bel material roll
N Card slot
y For SD/MMC cards
y Is not yet supported
O Signal interface USI
y 4 inputs / 8 outputs
y optional with 5 V or 24 V signal voltage
