Drive Belt Routing (1 over 1) Parts List
Item
Part #
Description
Qty
1
374006 “Long Belt” Double Sided
1
2
374020 “Short Belt” Double Sided
1
3
374021 "Short Belt” Single Sided - 84T
1
4
376022 Sprocket Altered
3
5
356029 Pulley, 26T 1/5P
2
6
284025 Pulley, 14T DFL ¼ ID
1
7
244012 Pulley, 14T SFL ¼ ID
3
8
374028 Pulley, 14T DBL 3/8 ID
1
9
374007 Pulley, Double Drive
1
