Users Manual Model 676 Appendix B • •• • 65
Head Driver Board P/N 371106TT
U - 30
U - 9
U - 10
U - 20
U - 5
U - 8
(Use chip removal tool p/n. 351156 for square I.C.'s)
HEAD DRIVER BOARD
Align angled corners of chip with socket and arrow denotes pin #1 or dimple on chip.
