3 dimensional drawing am3111, 1 radial / axial forces at the shaft end, 2 characteristic torque / speed curves – BECKHOFF AM3100 User Manual
Page 27
Advertising
Drive Technology
10 Technical data
AM3100 Version:
1.4
27
10.3 Dimensional
drawing
AM3111
10.3.1 Radial / axial forces at the shaft end
10.3.2 Characteristic torque / speed curves
Characteristic torque / speed curves see section 10.5.
Resolver
Motor type
x - without brake
x1 - with brake
AM3111 91
122
