LBO-DVI-AD User’s Manual
Link Bridge
TM Fiber Optic DVI Video ConvertingTransmitter System
Broadata Technical Support, (800) 214-0222 12
2.2.2 Optical Fiber Connection
Most cable manufacturers identify individual fibers in the fiber
cable. Select an appropriate terminated fiber. Each unit’s optical
ports in the system are specified for use with Multimode
(62.5/125 or 50/125 micron) fiber. Follow the ensuing
instructions on installing and connecting the fiber optic links:
1. Ensure the power is off before proceeding with the fiber
optic cable installation.
2. Prior to connecting the fiber optic cables, remove and save
the dust caps from the optical port of the LBO-DVI-AD units.
Clean the fiber optic connector and use a lint-free cloth
dampened with alcohol to thoroughly wipe the side and end
of the ferrule.
3. Connect the fiber from one unit to the other connecting the
near end LBO-DVI-AD-T unit’s optical port to the far end of
the LBO-DVI-AD-R unit’s optical RX port as illustrated in
Figure 2-5.
