BCI 6820E/6821E User’s Manual
Fast Ethernet Switching Converter
Broadata Technical Support, (800) 214-0222
8
4.0 SPECIFICATIONS
Standards
IEEE 802.3 & IEEE 802.3u
Switching Mechanism Store & Forward
MAC table
1K Entries
Forward & Filter Rate
10Base-T 14,800 pps
(64 Bytes)
100Base-TX 148,800 pps
LED
Power, FDX, TP 100, TP Link/Act,
Fiber 100, Fiber Link/Act
Power
DC 5V, 1.6A
Power Consumption
5W
Weight
0.6 Kg
Dimensions
71mm x 97mm x 26mm(W x D x H)
Temperature
Operating: 0 ~ 50
o
C
Storage: -20 ~ 60
o
C
Humidity
5% ~ 90% RH
Safety
UL, CSA
Emission
FCC/CE Class A
For further reports, please contact us for
update
UTP
Cat. 5 UTP cable
Fiber
Multimode 50/125, 62.5/125
Singlemode 9/125
5.0 REAR PANEL DIP SWITCH
Pin 1
Off/On
TP Auto-negotiation
Enable/Disable
Pin 2
Off/On
TP Speed
100M/10M
Pin 3
Off/On
TP Duplex
Full / Half
Pin 4
Off/On
Link Alarm
Disable/Enable
Default set OFF from PIN 1 to PIN 4
Please perform Power On reset after modifing the Dip Switch
setting.
