Hardware Installation
Memotec Inc. 4-3
4.2 Installing the SDM-9600 Chassis in a Rack
The SDM-9600 chassis is designed with rackmount ears for installation in a standard 19"
rack (see
Figure 4-1 on page 2 ). Rack requirements are discussed on page 2 .
To install the SDM-9600 chassis in a rack:
1. Carefully insert the SDM-9600 chassis into the front of the rack
2. Secure each rackmount ear onto the rack using 2 mounting screws with washers.
