AN219 - Rev. A
MDX420 PLR5779 Demod Card Installation
Page 2
2.
Gently press the PLR5779 Demod Card onto the appropriate header of the ASR5778
board.
Note: Demods must be installed in consecutive order as identified in figure 2. (i.e The
second Demod would be installed in the Demod 2 position).
Figure 2. Demod Locations
Demod 3
Demod 2
Demod 4
Demod 1
