32 Scoreboard Options
6.4 Changeable Captions
Team name and statistics caption kits contain hardware for one caption only and consist of an
upper caption retainer, a lower caption retainer, a changeable caption panel and screws.
The standard HOME and GUEST captions are applied directly to the face of the scoreboard.
Team name captions are on changeable panels that fit into retainers mounted above and
below the standard captions. If these retainers are not already present, attach the retainers
included with the caption kit.
Caption kits are also available for certain statistics display models to switch between
basketball, volleyball, wrestling, and hockey modes.
Refer to Drawing A-150021 in Appendix C for changeable caption installation instructions.
6.5 Time Outs Left (TOL) Digits
Certain scoreboards have the option to add a time outs left (TOL) digit for both the home and
guest teams. These digits are installed by simply unscrewing the blank face panel, connecting
and securing the digit, and manually applying the “T.O.L.” caption. Refer to Drawing A-
149030 in Appendix C for more information.
6.6 Double Bonus Indicators
All of the clock/score basketball scoreboards in this manual have the option to include
double-bonus indicators, which are factory installed. This option is illustrated in the electrical
and signal specification drawings in Appendix B for each scoreboard model.
6.7 Team Name Message Centers & Electronic Captions
Refer to Section 7 for more information about Team Name Message Centers and electronic
captions.
