Scoreboard Troubleshooting 9
When troubleshooting driver problems, several LEDs provide diagnostic information.
The number of LEDs and their function depends on the driver type.
Note: While it is necessary to have the scoreboard powered on to check the LED indicators,
always disconnect scoreboard power before servicing.
16-Col
umn “Gyrus” Drivers
LED Function Operation Summary
DS1
Radio/
RS-232 RX Blinking
or off DS1 will be blinking when the driver is receiving radio signal
and off when there is no signal.
DS2 Status Blinking
DS2 will be blinking at one second intervals to indicate the
driver is running.
DS5 Signal RX
Blinking
or off DS5 will be blinking when the driver is receiving current loop
signal and off when there is no signal.
DS8 Power Steady on DS8 will be on and steady to indicate the driver has power.
16-Column Drivers (prior to April 2015) & 4-Column Drivers
LED Color Function Operation Summary
DS1
DS2
DS7
Green Power Steady on
DS1 (16-column) / DS2 (4-column) / DS7 (4-
column MASC) will be on and steady to indicate
the driver has power.
DS2
DS1
DS8
Red Signal RX
Steady on
or blinking
DS2 (16-column) / DS1 (4-column) / DS8 (4-
column MASC) will be on or blinking when the
driver is receiving a signal and off when there is no
signal.
DS3 Amber Status Blinking
DS3 will be blinking at one second intervals to
indicate the driver is running (not available on 4-
column LED drivers).
Multiple Drivers
Scoreboards that require multiple drivers operate using a primary/secondary driver
configuration. The two drivers have been designed to simply plug into one another, and this
is done at the factory, so no additional on-site connection is necessary.
If it appears as though only a certain group of digits on the scoreboard is not functioning,
there may be a problem with the secondary driver(s) or the power/signal connection from
the other driver(s).
Note: The BB-2117 and BB-2119 require an interconnect cable between their driver
and the driver in the BB-2116. Refer to appropriate schematics listed in Appendix B.
