Gas Price 6-3
Display Operation
LCD Screen Action
LINE PRICE
1
↓
$1.23 9/10
<EDIT> TO MODIFY
1
↓
$1.23 9/10
The display will toggle between these two
screens.
Press the up or down arrow keys < ↑↓ > to scroll
through the current setting for any of the lines
on the display.
Press the < ENTER/EDIT > key to modify any of
the line settings.
Modifying Price Line Settings
The gas price can be modified either by pressing the < EDIT > key during operation
(see Gas Price Controller Operation) or using the < MENU > key (see Menu Items).
Refer to the following key to identify the item to be edited.
L = Current line number to be edited
D.CC = Current dollars and cents value to edit
T = Current tenths of cent value to edit
LCD Screen Action
EDIT LINE L
$D.CC T/10
↓
Press any of the number keys to edit the price
value for this line. Press the down arrow key < ↓ >
to modify the value of the 1/10-cent data for this
line (see note below).
Press < ENTER > to accept the new value or press
< CLEAR > to abort the changes.
Note: The flashing asterisk on the LCD shows
the current data being edited.
Many displays do not have a changeable 1/10-
cent digit. Changing the tenths-cent value from 9
on these digits will make the digit appear
incorrect.
Dimming
The dimming level of the Gas Price display can be adjusted in two ways. A
temperature/light sensor, mounted near the display, can detect the level of ambient
light at the display location and dim the sign's LEDs accordingly. This function is
known as automatic dimming. When the manual dimming function is selected, the
