Daktronics Gen VI Radio - Manual (Page 32)

THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS
DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT
REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED
WRITTEN CONSENT OF DAKTRONICS, INC.
COPYRIGHT 2013 DAKTRONICS, INC.
DAKTRONICS, INC.
DRAWN: DATE:
SHEET JOB NO: REV
INDOOR SCOREBOARDS
RADIO INSTALLATION DETAILS; SCOREBOARDS
KSCHNABEL 21 MAR 13
P 1749 F 10 A
1 = 8
KSCHNABEL
1130990
02
INSTALLATION INSTRUCTIONS:
INSTALLATION INSTRUCTIONS:
SCOREBOARD INTERNAL
HORIZONTAL STIFFENER
ATTACH RC-100 BASE ASSEMBLY
TO SCOREBOARD HORIZONTAL
WITH ADHESIVE VELCRO SUPPLIED
WITH ASSEMBLY
ANTENNA
FRONT OF
SCOREBOARD
BOTTOM OF RC-100
SCOREBOARD
HORIZONTAL
ATTACH RADIO RECEIVER TO
SCOREBOARD HORIZONTAL WITH
ADHESIVE VELCRO SUPPLIED
WITH ASSEMBLY
ANTENNA
FRONT OF
SCOREBOARD
TOP SECTION VIEW
TOP SECTION VIEW
ANTENNA INSTALLATION DETAIL
ENSURE ANTENNA
CABLE REACHES
HOLE IN SCOREBOARD
SCALE: 1 = 16
MOUNTING PANEL
APPROX.
3/4"
GOLD
NUT
GOLD
WASHER
ANTENNA
CABLE
1/4" BLK NUTS
INCLUDED WITH
U-BOLTS
EXPLODED SIDE VIEW
ANTENNA PART NUMBER
AND SIZE WILL VARY
FRONT VIEW
ANTENNA AND U-BOLT
HOLE PATTERN
0'-1 3/4"
0'-2 1/4"
THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS
DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT
REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED
WRITTEN CONSENT OF DAKTRONICS, INC.
COPYRIGHT 2013 DAKTRONICS, INC.
DAKTRONICS, INC. THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS
DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT
REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED
WRITTEN CONSENT OF DAKTRONICS, INC.
COPYRIGHT 2013 DAKTRONICS, INC.
DAKTRONICS, INC.
AV
ENSURE ANTENNA
CABLE REACHES
HOLE IN SCOREBOARD
U-BOLT; 1/4-20 X 1-3/8",
BLK-OXIDE STEEL @2
NUT; 1/4 -20
ZINC PLATED @4
**INDOOR SCOREBOARDS ONLY**
DATE: REV BY:
01 27 MAR 14 KDD
PER EC-13907, ADDED INDOOR SCBD ONLY NOTE
DATE: REV BY:
02 20 NOV 14 ASF
REMOVED ASSEMBLIES FROM INSTALLATION
INSTRUCTIONS
