DMAT-AB Sports Controller for Abekas Mira Page 17 of 25
Enter Number +
[INS/ADD]
Add Element PB Add entered CLIP number to end of current
Playlist.
[ALT] + [INS/ADD]
or
[SHIFT] +
[INS/ADD]
Insert Element PB Insert current CLIP into current Playlist above
highlight bar.
Enter Number +
[ALT] + [INS/ADD]
or
[SHIFT] +
[INS/ADD]
Insert Element PB Insert selected CLIP into current Playlist above
highlight bar.
[DELETE ITEM] Delete Element PB Delete currently highlighted element in
Playlist.
[ALT] + [DELETE
ITEM]
Delete Playlist PB Delete current Playlist.
[LIST] Load Playlist PL
Load current Playlist and cue the currently
highlighted element.
Enter Number +
[LIST]
Load Playlist PL
Load entered Playlist number and cue first
element.
[ SHIFT ] + [UP
ARROW]
Display next clip
page
PB Display the next page of clips.
[ SHIFT ] + [DOWN
ARROW]
Display previous
clip page
PB Display the previous page of clips.
[ ALT ] + [UP
ARROW]
Step to next
element
PB Step to next element in current Playlist. Do
not cue.
[ ALT ] + [DOWN
ARROW]
Step to previous
element
PB Step to next element in current Playlist. Do
not cue.
[PREROLL]
Preroll to current
time
PB Search to current time minus preroll value.
[TAKE]
Transition from
P1 to P2
PB
Transitions from the current element on P1 to
the current element on P2 and executes the
previously set up transition
{CAM}
Load live
recording
EE Loads the live recording that is currently
assigned to that softkey.
[SHIFT] + {CAM}
Assign live
recording to
softkey
PB Allows operator to assign a live recording to
the softkey for easy recall.
{CLIP}
Load pre-
recorded clip
PB Loads the pre-recorded clip that is currently
assigned to that softkey.
[SHIFT] + {CLIP}
Assign pre-
recorded clip to
softkey
PB Allows operator to assign a pre-recorded clip
to the softkey for easy recall.
[DEL] + [SAVE
CLIP]
Delete currently
selected clip
PB Deletes the contents saved within that clip
number across all channels on the DMAT-AB
[DEL] + {CAM} OR
{CLIP}
Delete currently
selected clip
PB Deletes the content saved within that clip
number on the currently selected channel
[GANG] Gangs P1 + P2 PB Gangs P1 and P2 channels for simultaneous
playback
Current
Mode
Operation Function
Next
Mode
Description
[REC] E to E EE Go to EE mode.
[PLAY] Play CP Playout clip from its current location.
T-BAR or [SLOMO] Slomo CP Slomo clip from its current location
[SHIFT] + T-BAR Set Slomo Speed CP Set slomo speed without affecting current
transport mode.
CP
[REV] Slomo Reverse CP Slomo clip from its current location in
Reverse direction.
