6 ST100 Shuttle Box
d. RECORD SELECTOR SWITCHES
Mode S1 S2 S3 S4 S5 S6
Record Lockout OFF OFF OFF OFF OFF OFF
Assemble Record ON OFF OFF OFF OFF OFF
Crash Record OFF ON OFF OFF OFF OFF
Insert Record ON VID AUD1 AUD2 AUD3 AUD4 Active
On
NOTE: AUD3 & AUD4 should be ON ONLY for VTRs that support 4 channels of
audio, i.e.: D1, D2 and D3 type VTRs.
e. TIME CODE DISPLAY
Display timecode or CTL Tape Timer per the mode selector switch on the front panel of
the VTR. The Time Mode can be selected manually by pressing the [SHIFT] + [JOG]
keys, each press will step to the next Time Mode: CTL Tape Time, Timecode, VITC.
