DR Power RapidFire Premier Yard Tow Kit (August 2014 - Present) - Manual (Page 2)

7 5 M E I G S R O A D , P . O . B O X 2 5 , V E R G E N N E S , V E R M O N T 0 5 4 9 1
©2014 Country Home Products, Inc. All rights reserved 352221
Installing with Tray
1. Support the Beam with a Jack Stand or equivalent to hold the Beam up.
2. Remove the Support Leg if one is already installed using a two 9/16"
Wrenches.
3. Install four 2.5" Bolts (item # 6 in figure 1) and Locknuts (item #8) through
the Tray and Tow-Bar and tighten using two 9/16" Wrenches (Figure 3).
Lowering the Tow-Bar Jack Stand
1. Remove Both Hitch Clips and Clevis Pins from the Tow-Bar Jack Stand
(Figure 4).
2. Insert the Clevis Pins at the locations shown and secure with Hitch Clips
(Figure 5).
Attaching to Tow Vehicle
1. Attach the Tow-Bar to the Tow Vehicle with the supplied Clevis Pin and
secure with the Hitch Clip.
2. Secure the Tow-Bar Jack Stand in the up position before towing.
If you have any questions please contact us at www.DRpower.com or call 1-800-
DR-OWNER (376-9637) for assistance.
Clevis pin and
Hitch Clip
Figure 4
Tow-Bar
Jack Stand
Figure 3
Tray
Bolt and Locknut
Tow -Bar
The Tow-Bar Jack Stand must be rotated up to the transport position when
towing the Log Splitter. Failure to properly secure the Stand up in the
transport position could damage the machine when towing.
Clevis pin and
Hitch Clip
Figure 5
 Making sure the machine is securely attached to the vehicle is the
responsibility of the owner/operator. Failure to securely attach the
machine can cause damage to the Log Splitter or tow vehicle.

Do not tow the Log Splitter more than 3 mph or damage to the Log
Splitter or Tow Vehicle may occur.
