AV.io HD User Guide – Physical features
10
Indicator LED details
The color and action of the indicator LED depends on whether you are connected by USB 3.0 or USB 2.0. For
maximum performance, always use a USB 3.0 port and the included USB 3.0 cable. Note that frame capture rate
will be reduced when connected via USB 2.0.
If you’re not sure if your controller is USB 3.0 or USB 2.0, plug AV.io HD into the capture computer and look at
the indicator LED:
A solid blue LED means USB 3.0 and… a solid green LED means USB 2.0
Connection type/LED color USB 3.0 connection USB 2.0 connection
Solid red  Firmware update in
progress
 AV.io HD initializing
 Firmware update in
progress
 AV.io initializing
Blinking red Adjustment to VGA input in
progress Adjustment to VGA input in
progress
Solid green – USB 2.0 connection active
USB 3.0 (solid blue) or USB 2.0
(solid green) begins blinking
only green
Audio transferring successfully Video transferring successfully
Solid blue USB 3.0 connection active –
USB 3.0 (solid blue) or USB 2.0
(solid green) begins blinking
only blue
Video transferring successfully Audio transferring successfully
USB 3.0 (solid blue), now
blinking green and blue Video and audio transferring
successfully
–
USB 2.0 (solid green), now
blinking blue and green
–
Video and audio transferring
successfully
