8
Flow Control Division
Kammer Control Valves
Fig. 1: Typical valve series 132000 with series 2 actuator
Bonnet bolt
O-Ring (body/bonnet)
Insert, thread lock
Plug
Seat
Body
Actuator stem
Packing nut
Plug stem
Slotted nut
Test connection
(drawn rotated 90°)
Bonnet
Bellows seal
Coupling insert
Coupling screw
Coupling
Yoke rod nut
Yoke plate
Locknut
