PRODUCT INTRODUCTION
2
1-1 Product Specifications
CPU Support Intel ® 4th Generation Core processors
Max processor power up to 84W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel ® H81
Memory 2 x 240-pin DDR3/DDR3L SDRAM DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1600/1333 MHz architecture
Expansion Slots 1 x PCI Express X16 slot
-Support PCI Express Gen2 5GT/s data rate
1 x PCI Express X1 slot
-Support PCI Express Gen2 5GT/s data rate
Storage Intel ® H81 chipset
- 2 x SATA 2.0 connectors (3Gb/s data transfer rate)
- 2 x SATA 3.0 connectors (6Gb/s data transfer rate)
LAN Realtek RTL8111F Giga LAN chip
Support 10/100/1000Mbps
Audio Realtek ALC662 audio chip
-High Definition Audio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Support up to 6 x USB 2.0 ports (2 rear panel ports, 2 onboard USB
headers supporting 4 extra ports)
Support USB 2.0 protocol up to 480Mb/s
Support up to 2 x USB 3.0 ports (2 rear panel ports)
Support USB 3.0 protocol up to 5Gb/s
Internal
Connectors
1 x 24-Pin ATX power connector
1 x 4-pin ATX 12V power connector
2 x SATA 3.0 connectors
2 x SATA 2.0 connectors
2 x USB 2.0 headers
1 x CPU FAN header (4-pin)
1 x System FAN header (4-pin)
1 x Front panel header
1 x Front audio header
1 x Speaker header
1 x Clear CMOS header
1 x ME header
1 x VDDR_SEL header
Back Panel
Connectors
1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x VGA port
1 x COM port
2 x USB 2.0 ports
2 x USB 3.0 ports
1 x DVI-D port(H81MXV-D)
1 x HDMI port(H81MXV)
