Advanced
Note: AMT Confuguration/Intel (R)Rapid Start Technology items are unavailable on
B75M Motherboard .
► North Bridge/ME Subsystem/AMT Confuguration/Intel (R)Rapid Start Technology/On
board Device Configuration/SATA Configuration/Super IO Configuration/
Trusted Computing
Press <Enter> to go to its su�menu.
North Bridge
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
North Bridge Configuration
Memory Information
Memory Frequency 1333 Mhz
Total Memory 1024 MB (��R3)
Memory Slot1 1024 MB (��R3)
Memory Slot2 Not Present
Memory Slot3 Not Present
Memory Slot4 Not Present
Memory Configuration
Memory Configuration
Integrated Graphics [Auto]
Initate Graphic Adapter [Auto]
VT-d
[�isabled]
IG� Multi-Monitor [�isabled]
�VMT/FIXE� Memory [256M]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Reset
ESC: Exit
Keep IG� enabled based on the
setup options.
Advanced
► Memory frequency
This item displays the current using memory frequency information.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main F-Center Chipset Boot Power Health Security Save & Exit
▶ North Bridge
▶ ME Subsystem
▶ AMT Confuguration
▶ Intel (R)Rapid Start Technology
▶ Onboard �evice Configuration
▶ SATA Configuration
▶ Super IO Configuration
▶ Trusted Computing
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Reset
ESC: Exit
North Bridge Parameters
Advanced
