Foxconn 671MX User Manual
Page 36
31
Chapter 2 BIOS Description
8.8 CPU Temperature / System Temperature
The CPU / System temperature will be automatically detected by the system.
8.9 CPU / System FAN Speed
The CPU / System fan speed will be automatically detected by the system.
This menu can let you load the optimized defaults set by BIOS, which have set the
optimized performance parameters of system to improve the performances of
system components. You can select <Y> or <N> and then press <Enter> to load
or not load the optimized defaults.
9. Load Optimized Defaults
10. Set Supervisor / User Password
The access rights and permissions associated with the Supervisor password are
higher than those of a regular User password. The Supervisor password can be
used to start the system or modify the CMOS settings. The User password can
also start the system. While the User password can be used to view the current
CMOS settings, these settings cannot be modified using the User password.
When you select the Set Supervisor / User Password option, the following message
will appear in the center of the screen, which will help you to set the password:
Enter Password:
Enter your password, not exceeding 8 characters, then press <Enter>. The
password you enter will replace any previous password. When prompted, key in
the new password and press <Enter>.
If you do not want to set a password, just press <Enter> when prompted to enter
a password, and in the screen the following message will appear. If no password
is keyed in, any user can enter the system and view / modify the CMOS settings.
Password Disabled!!!
Press any key to continue …
11. Save & Exit Setup
When you select this option and press <Enter>, the following message will
appear in the center of the screen:
SAVE to CMOS and EXIT (Y/N)?Y
Press <Y> to save your changes in CMOS and exit the program; press <N> or
<ESC> to return to the main menu.
12. Exit Without Saving
If you select this option and press <Enter>, the following message will appear in
the center of the screen:
Quit Without Saving (Y/N)?N
Press <Y> to exit CMOS without saving your modifications; press <N> or <ESC>
to return to the main menu.
