3
“KAT” CARRIAGE
This parts list covers the operation and maintenance requirements of the following Gullco “KAT” all
position, variable speed travel carriages:
GK-200-RL, GK-200-RM and GK-200-RH
SPECIFICATIONS
MODEL SPEED RANGE
GK-200-RL 0.5 – 16.4 in/min [1.2 – 41.6 cm/min]
GK-200-RM 1 – 32.7 in/min [2.5 – 83.1 cm/min]
GK-200-RH 2.7 – 88.4 in/min [6.7 – 224 cm/min]
Weight of “KAT” carriage: 29 Lbs. [13 Kg.]
Vertical load capacity: 100 lbs. [45 Kg.]
(GK-200-RH with a high speed gear attachment = 50 lbs. [22 Kg.])
Drive motor: 24 VDC permanent magnet gear motor.
Supply voltage: Either 42, 115 or 230 VAC, single phase, 50/60 Hz., 200 watts.
Complies with: C.S.A. (File # LR 35006-7) & CE Certification.
GENERAL DIMENSIONS
9.18 [233.2]
8.72 [221.5]
14.81 [376.2]
10.14 [257.6]
10.68 [271.3]
