PART LIST CONTINUED
OWNER'S MANUAL
PAGE 28 HD-3400 ASSEMBLY
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
ITEM NO. PART NUMBER DESCRIPTION QTY.
36 026-01P4494 ROM WEAR PLATE HD-3400 1
37 026-01P4500 ROM PLATE 1
38 026-01P4508 31 LB. COUNTER WEIGHT 1
39 026-01PL0235-23 GRIP OPEN END Ø1.188" X 8.75" LG. 2
40 026-01PL2122 OVAL-SHAPED RUBBER FOOT 2
41 026-01PL2325 PLASTIC LIMITER 2
42 026-01PL2371 3.75" ROLLER PAD END CAP 4
43 026-01PL2553 FINISH CAP BODY, 2.3750" 4
44 026-01PL2561 PLUG BUMPER, COPED 2
45 026-01PL2564 GLIDE SLEEVE 2
46 026-01PL2565 3.15" X 1.57" CAP 1
47 026-01PL2566 CAP 1.97" X 3.94" 3
48 026-01T4025 SPACER - 1.50 X .250" WALL X .188 LG. 2
49 ROC-IT WEIGHT CAGE - A2 ROC-IT WEIGHT CAGE 1
50 013-1002008 1/4" X 16mm SAE FLAT WASHER (Ni) 1
51 013-1002010 5/16" SAE FLAT WASHER (Ni) 8
52 013-1002007 3/8" X 22mm FLAT WASHER (Ni) 14
53 013-1002006 1/2" X 27mm SAE FLAT WASHER (Ni) 26
54 013-1009002 1/2" CURVED WASHER (Ni) 4
55 013-1010003 5/16" INTERNAL LOCK WASHER (Ni) 8
56 013-1006003 3/8" SPLIT LOCK WASHER (Ni) 10
57 011-0704001 3/8-16UNC X .75" SQUARE HEAD (Ni) 1
58 011-0701004 5/16"-18UNC X 1.25" BHCS (Ni) 8
59 011-0701020 3/8"-16UNC X 1.00" BHCS (Ni) 6
60 011-0701084 3/8"-16UNC X 1.25" BHCS (Ni) W/ DRI-LOC PATCH 2
61 011-0701021 3/8"-16UNC X 1.25" BHCS (Ni) 2
64 011-0701049 1/2"-13UNC X 1.50" BHCS (Ni) 2
65 011-0702054 1/4"-20UNC X .625" FHCS (Ni) 1
66 011-0702006 3/8"-16UNC X 1.75" FHCS (Ni) 2
67 011-0702025 1/2"-13UNC X 1.25" FHS (Ni) 2
68 011-0116108 1/2"-13UNC X 1.25" LOW HEAD SHCS (Ni) 4
69 011-0116116 1/2"-13UNC X 3.25" LOW HEAD SHCS (Ni) 2
70 011-0116117 1/2"-13UNC X 3.50" LOW HEAD SHCS (Ni) 2
