ITEM NO. PART NUMBER DESCRIPTION QTY.
71 011-0116118 1/2"-13UNC X 3.75" LOW HEAD SHCS (Ni) 2
72 011-0116123 1/2"-13UNC X 5.00" LOW HEAD SHCS (Ni) 2
73 012-0504004 1/4"-20 UNC THIN NYLOCK NUT (Ni) 1
74 012-0504005 3/8"-16 UNC THIN NYLOCK NUT (Ni) 5
75 012-0504002 1/2"-13 UNC THIN NYLOCK NUT (Ni) 17
77 021-0003230 DECAL HOIST 1.625" X 6.0613" 1
79 021-0003322 DECAL PINCH POINT 1.25" X 2.31" (VERTICAL) 1
80 021-0003341 DECAL PINCH POINT 1.07" X 2.13" (HORIZONTAL) 3
83 021-0003627 DECAL HOIST 2.07" X 7.75" 2
85 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
86 021-0003900 HD-3200, 3300, 3400 WEIGHT STACK DECALS 1
87 021-0003908 HD-3400 ROM Decal 1
88 021-0003912 DECAL ADJUST 1-8 VERTICAL GREY BKGRND 1
89 021-0003914 DUAL SERIES EYEBALL DECAL 1
90 021-0003887 PLACARD HD-3400 LEG EXTENSION/LEG CURL 1
91 021-0003915 HD QR DECAL 1
92 011-0116145 3/8"-16UNC X 1.75" LOW HEAD SHCS (Ni) 1
93 011-0116153 3/8"-16UNC X 3.75" LOW HEAD SHCS (Ni) 1
94 011-0116146 3/8"-16UNC X 2.00" LOW HEAD SHCS (Ni) 1
95 021-0003093 DECAL MOVING PARTS 1.20" X 2.38" (HOR) 1
96 013-1002004 1/2" X 34mm USS FLAT WASHER (Ni) 1
97 019-0001006 THICK RUBBER DONUT 3.00" X .50" BLACK 4
PART LIST CONTINUED
OWNER'S MANUAL
PAGE 29 HD-3400 ASSEMBLY
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
