ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X2396 REAR LINK ASSEMBLY 1
2 026-01X2402 FOOT PLATE ASSEMBLY 2
3 026-01X2457 PULL ARM ASSEMBLY 1
4 026-01X2464 BASE FRAME ASSEMBLY 1
5 026-01X2465 FRONT LINK ASSEMBLY 1
6 026-01X2466 USER SUPPORT FRAME ASSEMBLY 1
7 026-01X2469 GRIP ASSEMBLY 2
8 026-01X2581 CROSS MEMBER ASSEMBLY 1
9 026-01X2588 HAND GRIP 2
10 026-01X2604 CROSS BAR ASSEMBLY 1
11 026-01X2605 HANDLE BAR ASSEMBLY 1
12 026-01X2606 MID LINK ASSEMBLY 1
13 010-01C0353 CABLE ASSEMBLY ROC-IT 203 - 145 7/16" LG. 1
14 018-0001003 4.50" CABLE PULLEY 3
15 019-0001001 PLUG BUMPER 5
16 022-01PD2056 SEAT PAD ASSEMBLY 1
17 026-01F0256 BACKING PLATE 1
18 026-01M1097 BEARING TRIM CAP 2
19 026-01M1103 THREADED CABLE ANCHOR 1
20 026-01M0660 SHAFT 1.00" X 4.69" LG. 7
21 026-01M0760 HEAVY FLANGED SPACER .391" I.D. X .50" LG. 2
22 026-01M0920 SHAFT 1.38" X 4.69" LG. 1
23 026-01M1041 SHAFT .750" X 5.85" LG 2
24 026-01P2650 CABLE SHIELD 1
25 026-01P2653 'H' PLATE 1
26 026-01PL2122 OVAL-SHAPED RUBBER FOOT 2
27 011-0101026 3/8"-16UNC X 1.00" BHCS (WZ) 10
28 011-0101047 1/2"-13UNC X 1.50" BHCS (WZ) 2
29 011-0107011 5/16"-18UNC X 1.25" HHB (WZ) 4
30 011-0407020 3/8"-16UNC X 1.75" HHB (WZ) 1
31 011-0107032 3/8"-16UNC X 2.50" HHB (WZ) 2
32 011-0107034 1/2"-13UNC X 3.25" HHB (WZ) 4
33 011-0101070 1/2"-13UNC X 4.00" HHB (WZ) 2
34 011-0107036 1/2"-13UNC X 5.75" HHB (WZ) 8
35 012-0104008 3/8"-16 UNC THIN NYLOCK NUT (WZ) 7
36 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 18
37 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 32
38 013-0302008 5/16" SAE FLAT WASHER (WZ) 4
39 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 20
40 014-0024004 3/4" I.D. THRUST WASHER 4
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 15 RS-1203 ASSEMBLY
