Adjustments may need to be made during the first few session of use. Refer to the chart above
for the points where adjustments to the cable tension may be made. The maintenance chart below
should be followed to ensure that your equipment remains safe to use and continues to operate
smoothly.
(To be performed monthly)
If plastic casing is cracked or cables are frayed, the cables should be replaced. Check all cable
bolts and cable attachments to be sure they are properly attached. Check slack in cables and readjust
cable tension if needed.
Tighten bolts as needed. Replace worn bushings. Inspect pull pin knobs to be sure
they are screwed on tightly.
(I.E. Lat bars, curl bars, etc.) Lube every 300 hours.
Wipe clean with a dust free rag. Lube once a month with Super Lube (Teflon lubricant).
DO NOT USE OIL TO LUBRICATE HOIST EQUIPMENT!
MAINTENANCE
CABLES:
MOVING PARTS:
ROTATING PARTS:
GUIDE RODS:
A S S E M B LY
C a b l e a d j u s t m e n t s
M A N U A L
FITNESS SYSTEMS
R
HOIST
Page - 15
FINE TUNING
Loosen jam nut and thread bolt
in/out to give the cable proper
tension. Re-tighten jam nut.
