HARDWARE LIST
CUSTOMER CATALOG
A
11-HEX-12212
1/2-13 x 2 1/2 HEX BOLT
10
Key
No. Qty.
Part Number
Description
B
11-HEX-123
1/2-13 x 3 HEX BOLT
5
C
11-HEX-12234
1/2-13 x 2 3/4 HEX BOLT
6
D
11-HEX-12414
1/2-13 x 4 1/4 HEX BOLT
2
E
11-HEX-12(13)312
1/2-13 x 3 1/2 HEX BOLT
2
F
11-HEX-38(16)1
3/8-16 x 1 HEX BOLT
7
G
11-HEX-38(16)212
3/8-16 x 2 1/2 HEX BOLT
1
H
11-HEX-38(16)2
3/8-16 x 2 HEX BOLT
1
J
11-HEX-383
3/8-16 x 3 HEX BOLT
1
K
11-HEX-38312
3/8-16 x 3 1/2 HEX BOLT
1
L
11-HEX-385
3/8-16 x 5 HEX BOLT
1
M
11-HEX-516(18)114
5/16-18 x 1 1/4 HEX BOLT FULLY THREAD
6
N
11-FLA-381
3/8-16 x 1 FLATHEAD BOLT
6
P
11-FLA-121
1/2-13 x 1 FLATHEAD BOLT
5
Q
13-FLT-12
1/2 WASHER
48
R
13-FLT-38
3/8 WASHER
21
S
13-FLT-516
5/16 WASHER
6
T
14-TBW-1
THRUST WASHER, 1
4
U
12-LOK-12T
1/2-13 THIN LOCK NUT
27
V
12-LOK-38
3/8-16 THIN LOCK NUT
7
W
11-FLA-12314
1/2-13 x 3 1/4 FLATHEAD BOLT
2
X
Y
Z
14-BRG-THRUST34
13-FLT-12SAE
14-TBW-34
THRUST BEARING
1/2" SAE FLAT WASHER
THRUST WASHER, 3/4
2
4
4
AA
13-LOK-38
3/8 SPLIT LOCK WASHER
4
