CONTINUED
Disconnect the blade assembly
from the wiper arm:
Put a cloth on the edge of the
lock tab to prevent scratches,
then push up on the lock tab
carefully with a flat-tip
screwdriver.
When replacing a wiper blade,
make sure not to drop the wiper
blade or wiper arm down on the
windshield.
Remove the blade from its holder
by grabbing the tabbed end of the
blade. Pull firmly until the tabs
come out of the holder. Pivot the blade assembly toward
the wiper arm until it releases
from the wiper arm. 2. 3.
Wiper Blades
Ma
int
e
na
nce
301
WIPER ARM
LOCK TAB
BLADE
