Features of your vehicle
D140105AEN
Electric chromic mirror (ECM) with
compass and HomeLink
® system
(if equipped)
Your vehicle may be equipped with a
Gentex Automatic-Dimming Mirror with a
Z-Nav™ Electronic Compass Display
and an Integrated HomeLink
® Wireless
Control System. During nighttime driving,
this feature will automatically detect and
reduce rearview mirror glare while the
compass indicates the direction the vehi-
cle is pointed. The HomeLink
® Universal
Transceiver allows you to activate your
garage door(s), electric gate, home light-
ing, etc.
(1) Channel 1 button
(2) Channel 2 button
(3) Status indicator LED
(4) Channel 3 button
(5) Rear light sensor
(6) Dimming ON/OFF button
(7) Compass control button
(8) Compass display
OEN046033N
CAUTION
• Do not install a ski rack, antenna,
etc. that is attached to the vehicle
using a magnet.
Anything
attached to the roof of the vehicle
with a magnet will effect the com-
pass operation.
• If the compass deviates from the
correct indication after repeating
the adjustment, have the com-
pass checked by an authorized
dealer.
• The compass may not indicate
the correct compass point in tun-
nels or while driving up or down a
steep hill. (The compass returns
to the correct compass point
when the vehicle moves to an
area where the geomagnetism is
stabilized.)
• When cleaning the mirror, use a
paper towel or similar material
dampened with glass cleaner. Do
not spray glass cleaner directly
on the mirror as that may cause
the liquid cleaner to enter the mir-
ror housing.
