BIOS SETUP
48 MB961 User’s Manual
Primary Display
Select which of IGFX/PEG/PCI graphics device should be primary
display or select SG for switchable Gfx.
Internal Graphics
Keep IGD enabled based on the setup options.
DVMT Pre-Allocated
Select DVMT 5.0 Pre-Allocated (Fixed) graphics memory size used by
the internal graphics device.
DVMT Total Gfx Mem
Select DVMT 5.0 total graphics memory size used by the internal
graphics device.
Gfx Low Power Mode
This option is applicable for SFF only.
Primary IGFX Boot Display (LCD Control)
Select the Video Device that will be activated during POST. This has no
effect if external graphics present. Secondary booty display selection will
appear based on your selection. VGA modes will be supported only on
primary display.
Memory Configuration
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Memory Information
→ ←
Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Memory Frequency 1333 MHz
Total Memory 8192 MB (DDR3)
DIMM#0 2048 MB (DDR3)
DIMM#1 Not Present
DIMM#2 2048 MB (DDR3)
DIMM#3 Not Present
CAS Latency (tCL) 11
Minimum delay time
CAS to RAS (tRCDmin) 11
Row Precharge (tRPmin) 11
Active to Precharge (tRASmin) 28
