12 SI-32-N User Manual
LPC I / O NCT6106
COM1 (RS232) (RJ45 same as original IB938)
Monitor (2 thermal inputs, 2 voltage monitor inputs
COM 2/3 with pin-9 with power for 2 ports (500 mA each
port)
Expansion slot 1x mPCIe(x1) 26.8 mm
1x mPCIe(x1) 51 mm (mPCIe & mSATA)
Digital IO 4 in & 4 out
Internal I/O
Audio Header for speaker out (w/ amplifier)
USB 2x 10-pin header for two USB 2.0 Do Not Populate For Si
System
Serial ATA 1x 10-pin header; Do Not Populate For Si System
Expansion Slot 1 x mPCIe(x1) 26.8 mm; 1 x mPCIe(x1) 51 mm (mPCIe &
mSATA)
Add-On Features
Watchdog, H/W monitoring, iSMART, LAN Wakeup
Dimensions
PCB
Dimensions
-
105mm x 205mm
Power
Power
-
12~24V DC in(+-10%)
