OPF-TH1000D/OPF-RH1000D User’s Guide
47
9.2 Product specification
9.2.1 OPF-H1000D
Item Description
Model number OPF-TH1000D (Transmitter) OPF-RH1000D (Receiver)
Input
Video
Number / Signal
1 input / HDMI (*1)
- HDCP: Pass through
- CEC: Pass through
- TMDS Single Link
- TMDS clock: 25 MHz to 165 MHz
1 input / Optical signal for extension
Connector 1 female HDMI Type A (*2) 1 LC connector
Others Color depth: 24bit
Formats
VESA: VGA/SVGA/XGA/WXGA (1280x768) /WXGA(1280x800)/Quad-VGA/
SXGA/WXGA(1360x768)/WXGA(1366x768)/SXGA+/WXGA+/WXGA++/
UXGA/WSXGA+/WUXGA
* WUXGA only supports Reduced Blanking
SDTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
Audio
Digital
Number / Signal
1 input / Multi-channel linear PCM
up to 8 channels
- Sampling frequency: 32 kHz
to 192 kHz
- Sample size: 16 bit to 24 bit
- Reference level:-20 dBFS
- Max. input level: 0 dBFS
1 input / Optical signal for extension
Connector 1 female HDMI Type A (*2) 1 LC connector
Analog (*4)
Number / Signal
1 input / Stereo LR unbalanced signal
- In
put impedance: 75 Ω
- Reference level: -10 dBu,
- Max. output level: +10 dBu
1 input / Optical signal for extension
Connector 1 stereo mini jack (3.5 mm) 1 LC connector
Output
Video
Digital
Number / Signal 1 output / Optical signal for extension
1 output / HDMI (*1)
- HDCP: Pass through
- CEC: Pass through
- TMDS Single Link
- TMDS clock: 25 MHz to 165 MHz
Connector 1 LC connector 1 female HDMI Type A (*2)
Daisy Chain
Number / Signal - 1 output / Optical signal for extension
Connector - 1 LC connector
Others Others Color depth: 24bit (*3)
Formats
VESA: VGA/SVGA/XGA/WXGA (1280x768) /WXGA (1280x800)/Quad-VGA/
SXGA/WXGA(1360x768)/WXGA(1366x768)/SXGA+/WXGA+/WXGA++/UX
GA/WS
XGA+/WUXGA
* WUXGA only supports output as Reduced Blanking
SDTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
Audio Digital Number / Signal 1 output / Optical signal for extension 1 output / Multi-channel linear PCM
