VK7
VK7 HDMI LCD Monitor QUICKSTART GUIDE
The MANUAL function allows you to change the values of Red, Green, and Blue (RGB).
This function recalls user defined values settings .The user setting will remain in memory
indefinitely and can be erased by using the reset option in the main menu.
The DSLR Scaling function will allow users to extend their DSLR camera’s HDMI video
output any option of four – Normal, 3:2, 16:9 or Full Screen – convenience made simple.
This function displays the blanking portion of the incoming signal.
The LCD panel in this display has a native display of 1024 x 600 pixels. A signal of any
other resolution is scaled to fit this native resolution. There may be time when it is
desired to view the incoming signal without scaling. Enabling Pixel to Pixel mode turns
off the scaling and displays a 1024x600 pixel window of the original image. Each pixel of
the panel displays one pixel of the original image. The user may use the arrow buttons
(buttons 3-6) on the monitor face to move the window left, right, up and down to see the
desired portion of the image.
The VK7 is equipped with Monochrome Peaking features which highlight the desired
focus area in a bright, red outline. The operator adjusts the focus control until the red
indicator outlines on the desired area are razor sharp, indicating optimal focus. For the
best results, be sure the subject is properly exposed.
The False Color feature utilizes a full spectrum of assigned color indicators, ensuring
flawless shot exposure. As the camera Iris is adjusted, the subject of the image will
change color based on specific brightness values indicating optimal exposure. See
included chart for color assignments.
As an additional tool associated with the VK7’s False Color feature, ikan’s exclusive
Adjustable Under Exposure and Over Exposed Waning feature gives the operator full
control of the VK7 False Color brightness values. By setting the preferred IRE exposure
limits, the operator is warned when the image exposure is exceeding or falling under
the preset IRE limit, providing customizable, full image exposure control.
The VK7 offers adjustable upper Clip Guide levels to accurately display overexposed
images in any shooting condition. The operator simply assigns the upper IRE to their
preference and any exposure over the set IRE limit will flash in a vivid purple, indicating
only the over exposed area.
This function displays a side by side comparison of the incoming video signal. Pushing
the F1/2 button one time will enter the mode. Each time the F1/2 button is pushed it
will freeze the current frame on the right hand side of the display while the left continues
to display the live signal. Pressing the exit button will exit the window mode. Use
Window 1 for 16:9 signals and Window 2 for 4:3 signals.
CONFIGURATION OF SETTING MENUS
Brightness 0-100
Contrast 0-100
Chroma 0-100
Sharpness 0-100
Tint 0-100
Color Temp. 5600 K
6500 K
9300 K
MANUAL
OSD Language English
Chinese
Spanish
French
OSD Duration 5-60 second
OSD Flip Yes /No
H Flip Yes /No
V Flip Yes /No
Luma Under Warn
Luma Over Warn
Fuction 1 Window 1
Window 2
HV Delay
Guides
Peaking
False
Color
Clip Guide
Underscan
DSLR
Scaling
Check Field
Pixel
Fuction 2 Window 1
Window 2
HV Delay
Guides
Peaking
False
Color
Clip Guide
Underscan
DSLR
Scaling
Check Field
Pixel
Menu Setup User 1-5
System Reset
