Page 35 HX300
8.3 FACTORY SERVICE
In the unlikely event that the radio fails to perform or needs servicing, please
contact the following:
For repairs In USA
Standard Horizon
Attention Marine Repair Department
6125 Phyllis Drive, Cypress, California 90630
Telephone (800) 366-4566
For repairs in Canada
Westcom Marine
488 East 62nd Avenue
Vancouver BC V5X2G1
Phone (604)327-6280
An “RA” Return Authorization number is not necessary to send a product in
for service. Include a brief note describing the problem along with your name,
return address, phone number, and proof of purchase.
8.4 TROUBLESHOOTING CHART
SYMPTOM PROBABLE CASE REMEDY
The key does not start the
scan.
No channel memorized. Enter desired channels into the
transceiver’s Scan memory. Refer
to section 6.9.1 “PROGRAMMING
SCAN MEMORY”.
Squelch is not adjusted. Press the key several times
until the “ SQL” indicator blinks,
then press the key until the
“ ” icon disappears. Further
adjustment of the squelch level
may eliminate incoming signal.
Cannot select between USA,
INTL, Canadian bands.
Proper operation not fol-
lowed.
Hold down the key and press
the key.
Speaker audio is not heard
when the key is press and
hold.
Low battery. Charge battery. Refer to section
4.2.3 “BATTERY CHARGING”.
Audio volume is too low. Press the key several times
until the “ VOL” indicator blinks,
then press the key several
times.
Some keys does not operate. Key lock is on. Hold down the key for 2 sec-
onds to turn the Key Lock off.
“ ” indicator on the LCD does
not appear while charging.
Detective battery FNB-
122LI.
Contact your Standard Horizon
dealer.
