Charger

Safety Notes

Read all safety warnings and

all instructions. Failure to fol-

low the warnings and instruc-

tions may result in electric

shock, fire and/or serious

injury.

Save all safety warnings and instructions for future refer-

ence.
The term “battery pack” used in these operating instructions

refers both to standard battery packs (battery packs with

holder on the bike frame) and to rack-type battery packs (bat-

tery packs with holder in the rear rack/carrier).

Keep the charger away from rain or moisture. The

penetration of water into a battery charger increases

the risk of an electric shock.

Only charge eBike-approved Bosch lithium-ion battery

packs. The battery-pack voltage must match the bat-

tery-pack charging voltage of the charger. Otherwise

there is danger of fire and explosion.

Keep the battery charger clean. Contamination can lead

to danger of an electric shock.

Before each use, check the battery charger, cable and

plug. If damage is detected, do not use the battery

charger. Never open the battery charger yourself.

Have repairs performed only by a qualified technician

and only using original spare parts. Damaged battery

chargers, cables and plugs increase the risk of an electric

shock.

Do not operate the battery charger on easily inflamma-

ble surfaces (e.g., paper, textiles, etc.) or surround-

ings. The heating of the battery charger during the charg-

ing process can pose a fire hazard.

Vapours can escape in case of damage and improper

use of the battery pack. Provide for fresh air and seek

medical attention in case of complaints. The vapours

can irritate the respiratory system.

Supervise children. This will ensure that children do not

play with the charger.

Children or persons that owing to their physical, sensory

or mental limitations or to their lack of experience or

knowledge, are not capable of securely operating the

charger, may only use this charger under supervision or

after having been instructed by a responsible person.

Otherwise, there is danger of operating errors and injuries.

Please read and observe the safety warnings and in-

structions enclosed in the operating instructions of the

battery pack and drive unit/HMI, as well as in the oper-

ating instructions of your eBike.

A short version of important safety warnings in English,

French and Spanish with the following content can be

found on the bottom side of the charger (marked with num-

ber C4 in the representation on the graphics page):

– For safe operation see manual. Risk of electric shock.

– Dry location use only.

– Charge only batteries of the Bosch eBike Systems.

Other batteries may burst causing personal damage.

– Do not replace the plug assembly as risk of fire or elec-

tric shock may result.

Product Description and

Specifications

Product Features (See page 6

8)

The numbering of the product features refers to the illustra-

tion of the battery charger on the graphics page.

C1 Battery charger
C2 Charger socket
C3 Plug-in connector
C4 Safety warnings, charger
C5 Charge connector
C6 Socket for charge connector
C7 Charge socket cover
A2 Rack-type battery pack
A3 Battery charge-control indicator
A4 Battery on/off button
A8 Standard battery pack
