1 | inputs and outputs – Lencore n.Form: MPI-6 User Manual

Page 6

Advertising
background image

section 2

2.1 |

inputs and outputs

4

•

Power input.

•

POTS line input (RJ11).

•

Ground 2-pos terminal block (screw terminals).

•

iLON input 2-pos terminal block (screw connectors).

•

6 audio inputs (RCA connectors):

1.

Audio 1 (stereo)

2.

Audio 2 (stereo)

3.

Audio 3 (stereo)

4.

Audio 4 (stereo)

5.

Audio 5 (stereo) (iNET Music)

6.

Audio 6 (mono) (iNET Page)

•

Page on/off 2-pos terminal blocks (screw terminals) to activate different page zones.

•

Auxiliary inputs (2). For triggering the two aux output relays.

inputs

•

Global MPI output (RJ45).

•

Data output to OPs (RJ45) with two audio sources.

•

11 Relay outputs (9- SPST, 2- DPDT).

•

Audio output (RJ45) for the additional four audio sources.

outputs
