1 2 3 4
VIDEO SERVER
audio input
OR
IP NETWORK CAMERA
audio input
INTERCONNECTION DIAGRAM
FOR
CONNECTING LOUROE VERIFACT MICROPHONES
TO A DVR WITH MULTIPLE AUDIO INPUTS USING
LOUROE MODEL IF-4 AUDIO INTERFACE ADAPTER
1 1 1 1
+12 Vdc POWER
SUPPLY (INCLUDED)
1
E
L OUROE
LECTRONICS
IF-4 FOUR ZONE AUDIO INTERFACE ADAPTER
AUDIO OUTPUTS
MIC INPUTS
AUDIO LEVEL CONTROL
BLACK
BARE
RCA output
Use 3.5mm adaptor of IF-4
for connection to
IP Camera or Video Server
Audio Out
Audio Indicator Light
Audio Test Switch
Audio In
BARE
A B C
V E R I FA C T A
L
N
A B C
V E R I FA C T A
L
N
BLACK
RED
All Louroe microphones
VERIFACT A, B, C, D, D-V, E, K, L-DT
are compatible with Louroe IF-2,
IF-4 and IF-8 Audio Interface Adapters
Verifact A Microphone shown as an example
with IF-4 Interface Adapter
IF-4 will accommodate up to
4 Louroe microphones
Back side of
Verifact A Microphone Shown
2 3 4
LOUROE MODEL IF-4
AUDIO INTERFACE ADAPTER
AUDIO OUT AUDIO IN
RCA CABLE CONNECTS FROM
“AUDIO OUT” OF IF-4 TO
“AUDIO IN” OF DVR, ETC.
DVR WITH RCA TYPE AUDIO INPUTS
A
A
B
B
C
C
A B C
V E R I FA C T A
L
N
A B C
V E R I FA C T A
L
N
2 CONDUCTOR
SHIELDED
22 GAUGE
WEST PENN
452 OR EQUIV.
ON RS
1 2 3 4
R
RED
Audio Path
INSTALLATION AND OPERATING INSTRUCTIONS
Page 3 of 4
