Louroe Electronics ASK-4 304 - Manual (Page 4)

SPECIFICATIONS (IF-4 Interface Adapter)
Audio Input Impedance
Input (3-pin terminal block)
Audio Output Impedance
Audio Output Gain
17.5kΩ
Line Level (0dB@1KΩ )
Up to +10dB
Power Requirements +12 Vdc, 500mA
11½”L x 4¾”W x 1¼”H
600Ω @ 1kHz
Dimensions
Weight 12.5 oz
INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT NOTICE
When this equipment is used as part of an audio monitoring
system, the law requires that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A decal notice is included
with each microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18. Crime and Criminal
Procedure, Sec 2510.
Page 4 of 4
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX 994-6458
website: www.louroe.com e-mail: [email protected]
(818) ®
WARRANTY
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
®
®
®
®
®
®
AUDIO
MONITORING
On
These Premises
®
SPECIFICATIONS (Microphone - Model A)
Type
Frequency response
Current drain
Output
Supply voltage
Electret Condenser
50 Hz to 15 kHz ± 1 dB
10 mA
Line Level (0 dB 600 W @ 1 kHZ)
12Vdc
Dimensions
Weight
Weight of the kit
3.5 oz
4 lbs
4"Dia x 1 ½"H
Ask4_304_inst_2/15
