CIO-PDISO8 User's Guide Specifications
16
Environmental
Table 4. Environmental specifications
Operating temperature range 0 to 50 °C
Storage temperature range -20 to 70 °C
Humidity 0 to 90% non-condensing
Main connector and pin out
Table 5. Main connector specifications
Connector type 37-pin D type (male)
Dielectric strength >1000 Vrms
Current rating 2 A
Compatible cables C37FF-x, where x = length in feet
C37FFS-x, where x = 5 or 10 feet
Compatible accessory products with the
C37FF-x and C37FFS-x CIO-MINI37
SCB-37
Table 6. Connector pin out
Pin Signal Name Pin Signal Name
1 Input 7A 20 Input 7B
2 Input 6A 21 Input 6B
3 Input 5A 22 Input 5B
4 Input 4A 23 Input 4B
5 Input 3A 24 Input 3B
6 Input 2A 25 Input 2B
7 Input 1A 26 Input 1B
8 Input 0A 27 Input 0B
9 Relay 7 (C) 28 Relay 7 (NO)
10 Relay 6 (C) 29 Relay 6 (NO)
11 Relay 5 (C) 30 Relay 5 (NO)
12 Relay 4 (NC) 31 Relay 4 (C)
13 Relay 4 (NO) 32 Relay 3 (NC)
14 Relay 3 (C) 33 Relay 3 (NO)
15 Relay 2 (NC) 34 Relay 2 (C)
16 Relay 2 (NO) 35 Relay 1 (NC)
17 Relay 1 (C) 36 Relay 1 (NO)
18 Relay 0 (NC) 37 Relay 0 (C)
19 Relay 0 (NO)
