USB-DIO96H/50 User's Guide Specifications
17
P2
Table 9. P2 pinout
Pin Signal name Pin Signal name
100 GND 99 +5V
98 THIRDPORTC Bit 0 97 THIRDPORTC Bit 1
96 THIRDPORTC Bit 2 95 THIRDPORTC Bit 3
94 THIRDPORTC Bit 4 93 THIRDPORTC Bit 5
92 THIRDPORTC Bit 6 91 THIRDPORTC Bit 7
90 THIRDPORTB Bit 0 89 THIRDPORTB Bit 1
88 THIRDPORTB Bit 2 87 THIRDPORTB Bit 3
86 THIRDPORTB Bit 4 85 THIRDPORTB Bit 5
84 THIRDPORTB Bit 6 83 THIRDPORTB Bit 7
82 THIRDPORTA Bit 0 81 THIRDPORTA Bit 1
80 THIRDPORTA Bit 2 79 THIRDPORTA Bit 3
78 THIRDPORTA Bit 4 77 THIRDPORTA Bit 5
76 THIRDPORTA Bit 6 75 THIRDPORTA Bit 7
74 FOURTHPORTC Bit 0 73 FOURTHPORTC Bit 1
72 FOURTHPORTC Bit 2 71 FOURTHPORTC Bit 3
70 FOURTHPORTC Bit 4 69 FOURTHPORTC Bit 5
68 FOURTHPORTC Bit 6 67 FOURTHPORTC Bit 7
66 FOURTHPORTB Bit 0 65 FOURTHPORTB Bit 1
64 FOURTHPORTB Bit 2 63 FOURTHPORTB Bit 3
62 FOURTHPORTB Bit 4 61 FOURTHPORTB Bit 5
60 FOURTHPORTB Bit 6 59 FOURTHPORTB Bit 7
58 FOURTHPORTA Bit 0 57 FOURTHPORTA Bit 1
56 FOURTHPORTA Bit 2 55 FOURTHPORTA Bit 3
54 FOURTHPORTA Bit 4 53 FOURTHPORTA Bit 5
52 FOURTHPORTA Bit 6 51 FOURTHPORTA Bit 7
