1-2 Overview 978697 Daq Systems
DaqBooks, DaqBoards and Daq PC-Cards
Daq products connect to one or more DBKs on their signal input side and a computer on their output side.
Each type of Daq device connects to the computer in a different way:
• The DaqBook is an external module that connects to a computer’s enhanced parallel port (EPP)
interface or PC-Card link.
• The DaqBoard [ISA type] board is an internal card that plugs into an ISA-bus slot within a
computer.
• DaqBoard/2000 Series Boards plug into a PCI-bus slot, within a host PC.
• cPCI DaqBoard/2000c Series boards plug into a cPCI-bus slot, within a host PC.
• The Daq PC-Card slides into the PCMCIA slot of a host computer, typically a notebook PC.
Features common to the Daq products include:
• 100-kHz channel-to-channel scan and gain switching (10 µs);
200-kHz for DaqBoard/2000 Series and DaqBoard/2000c Series Boards.
• 512-location sequence memory that can be loaded with any combination of channels and gains.
• Ability to access up to 256 different channels of DBK signals while maintaining the channel-to-
channel scan rate. The DBK expansion options can accommodate mixed-signal inputs from
thermocouples and RTDs to isolated high-voltage inputs and strain gages.
• Ability to handle 8 differential or 16 single-ended signal inputs without DBK expansion units.
• Ability to handle fixed digital I/O up to 4 TTL lines in and 4 TTL lines out (accessible only if no
analog expansion cards are in use).
The following table lists various features of DaqBooks, ISA-DaqBoards, and Daq PC-Cards. Note that
PCI and cPCI-type DaqBoards (the DaqBoard/2000 Series and DaqBoard/2000c Series Boards) are
covered in separate documentation.
Daq Products, Models and Features
Models
A/D
Resolution
Analog
Output
Channels
Unipolar/
Bipolar
Selection
Single-
ended/
Differential
Selection
Programmable
Digital I/O
Lines
Program
mable
Counter/
Timers
Size
(inches)
Power
Consumption
DaqBooks
DaqBook/100 12 bit 2 Jumper Jumper 16 high speed
24 gen purpose
5 ch
7 MHz
8.5×11
×1.375 510 mA @ 12V
DaqBook/112 12 bit 2 Jumper Jumper N/A N/A 8.5×11
×1.375 360 mA @ 12V
DaqBook/120 12 bit 2 Jumper Jumper 16 high speed
24 gen purpose
5 ch
7 MHz
8.5×11
×1.375 510 mA @ 12V
DaqBook/200 16 bit 2 Software Software 16 high speed
24 gen purpose
5 ch
7 MHz
8.5×11
×1.375 620 mA @ 12V
DaqBook/216 16 bit 2 Software Software N/A N/A 8.5×11
×1.375 600 mA @ 12V
DaqBook/260 16 bit 2 Software Software 16 high speed
24 gen purpose
5 ch
7 MHz
11×13
×3.5
620 * mA @ 12V
ISA-DaqBoards
DaqBoard/100A 12 bit 2 Sequencer Software 16 high speed
24 gen purpose
5 ch
7 MHz
4.5×13.125 1330 mA @ 5V
DaqBoard/112A 12 bit 2 Sequencer Software N/A N/A 4.5×13.125 970 mA @ 5V
DaqBoard/200A 16 bit 2 Sequencer Software 16 high speed
24 gen purpose
5 ch
7 MHz
4.5×13.125 1700 mA @ 5V
DaqBoard/216A 16 bit 2 Sequencer Software N/A N/A 4.5×13.125 1340 mA @ 5V
Daq PC-Cards
Daq/112B 12 bit N/A Bipolar
Only
Software N/A N/A 3.375×0.2 160 mA @ 5V
Daq/216B 16 bit N/A Bipolar
Only
Software N/A N/A 3.375×0.2 160 mA @ 5V
* Does not include power consumption of internal DBK options.
