OPEN
8
7
6
5
4
3
2
1
Active Low oDATA
OPEN
8
7
6
5
4
3
2
1
Active High oDATA
(default)
S3
oDATA POL
S3
oDATA POL
Polarity Selection for the Output Port Data Lines
2.2.2.3.7 S3-7 TRIGGER POL: Output Trigger Control Line Polarity
The trigger control line may be set for active low or active high operation. Default is
active high.
Active Low oTrigger
Active High oTrigger
(default)
OPEN
8
7
6
5
4
3
2
1
OPEN
8
7
6
5
4
3
2
1
S3
TRIGGER POL
S3
TRIGGER POL
Polarity Selection for the oTrigger Line
2.2.2.3.8 S3-8 CLR POL: Output Clear Control Line Polarity
The Output Clear control line can be selected for active low or active high. Default is
active high.
