Measurement Computing Digital488 User Manual
Page 14
Section 1
Introduction
1.3d
General
Configuration:
Five 8-bit ports, programmable as inputs or outputs. Also included are programmable
handshake lines, data latching capability, Clear and Trigger outputs, and a Service Request (SRQ) input.
Dimensions:
205 mm deep x 115 mm wide x 28 mm high (8" x 4.5" x 1.1").
Weight: 0.23 kg. (0.5 lbs).
Operating Environment:
Standard: Indoor, 0
° to 50°C; 0 to 70% RH to 35°C. Linearly derate 3% RH/°C from 35 to 50 °C.
Controls:
IEEE parameter switches.
Indicators:
LED indicators for IEEE TALK, LISTEN, SRQ, ERROR, and POWER.
Power:
User suupplied +5 volts ±0.25% at 1 amp. Mating power connector with 8 inch leads provided.
:$51,1*
Do not use this interface outdoors! The interface is intended for indoor use only!
Outdoor conditions could result in equipment failure, bodily injury, or death!
&$87,21
Never disassemble the interface case while it is connected to the AC power line!
Internal voltage potentials exist which could cause bodily injury or death!
