16 Net232 User’s Guide, 1037-0901, rev 2.0
Specifications
Ethernet Interface
TCP/IP parameters are configured using the serial configuration port.
Protocol: TCP/IP
Media: 10BASE-T
Interface: RJ-45 shielded connector
Serial Interface
All parameters are configured using the Ethernet Interface.
Serial Ports: Port 1 - used for TCP/IP configuration and serial communications.
Port 2 - used for serial communications.
Electrical Characteristics: Supports RS-232.
Duplex: Full.
Data Bits: 7 or 8.
Stop Bits: 1 or 2.
Parity: Odd, even, or none.
Baud Rates: 300, 1200, 2400, 4800, 9600, 19200, 28800, 38400, 57600, 115200
Terminator: CR, LF, CR-LF, User, or None
Control: Supports Clear To Send/Request To Send, Data Terminal Ready/Data Set Ready, XON/XOFF, or None.
Connector: Accepts 9-pin sub D female: DCE configured.
General
Indicators: LED’s for Ethernet Activity, Ethernet Link, and Power.
Power: 105 to 125V or 210 to 250V, 50/50 Hz; 10 VA max.
Environment: 0 to 50
° C; 0 to 95% RH non-condensing.
Dimensions: 190mm long x 138mm wide x 68mm high (7.5 x 5.4 x 2.7 inches)
Weight: 1.1 kg (2.3 lbs)
Controls: Power switch (rear panel)
